Yokogawa EJX530B - Manual (Page 69)

<9. Maintenance>
9-10
IM 01C27F01-01EN
Connect the device configuration tool and check self-diagnostics.
Contact Yokogawa service personnel.
F0909.ai
Are valves opened or
closed correctly?
Is impulse piping
connected correctly?
Refer to Alarm Message
Summary in Subsection 9.5.3.
Provide lagging and/or cooling, or allow
adequate ventilation.
Refer to subsection 9.2 "Calibration
Instruments Selection".
Fully open valve.
Refer to individual model user manuals
and connect piping as appropriate for
the measurement purpose.
Adjust the output.
Is transmitter
installed where there is
marked variation in
temperature?
Is output adjusted correctly?
Large output error.
Does the self-
diagnostic indicate problem
location?
Were appropriate
instruments used for
calibration?
YES
NO
YES
NO
NO
YES
NO
YES
NO
YES
NO
YES
