Parameters Value Range Default Appears If
[`LLO] [``rL] to [`LHI] or [``rH] if [`LHI] is not active [``rL] [`Ot1] is set to [`H_L] or
[``LO] and [`LOC] is not set
to
[```3].
[`LHI] [`LLO] to [``rH] or [``rL] if [`LLO] is not active [``rH] [`Ot1] is set to [`H_L] or
[``HI] and [`LOC] is not set
to
[```3].
[`ALO] [``rL] to [`AHI] or [``rH] if [`AHI] is not active [``rL] [`Ot2] is set to [`PrA] or
[``Pr] and [`LOC] is set to
[```0] or [```1].
[`AHI] [`ALO] to [``rH] or [``rL] if [`ALO] is not active [``rH] [`Ot2] is set to [`PrA] or
[``Pr] and [`LOC] is set to
[```0] or [```1].
[`CAL] -180°F to 180°F/-100°C to 100°C; 0 [`LOC] is set to [```0] or
or -18.0°F to 18.0°F/-10.0°C to 10.0°C [```1].
4 . 6 ■ S e t u p W a t l o w S e r i e s 9 4
Setup
Table 4.6 -
Operation Menu
Prompts and Descriptions.
Operation Menu
Document your Series 94 Operation Parameters
Do not enter any values here; make photocopies instead.
NOTE:
Shaded parameters
may not appear,
depending on the
controller’s configu-
ration and model
number.
Operation Parameters
Low Limit Set Point Sets the low limit set point. Active if [`Ot1] is set to [`H_L]
or [``LO].
Range: [``rL] to [`LHI], or [``rH] if [`LHI] is not active.
High Limit Set Point Sets the high limit set point. Active if [`Ot1] is set to
[`H_L] or [``HI].
Range:
[`LLO] to [``rH], or [``rL] if [`LLO] is not active.
Alarm Low: Represents the low process alarm. This parameter will not appear if
[`Ot2] is set to [``no]. This parameter is present if [`Ot2] is set to [`PrA] or
[``Pr] and [`LOC] is set to [```0] or [```1].
Range:
[``rL] to [`AHI], or [``rH] if [`AHI] is not active. Default: [``rL]
Alarm High: Represents the high process alarm. This parameter will not appear if
[`Ot2] is set to [``no]. This parameter is present if [`Ot2] is set to [`PrA] or
[``Pr] and [`LOC] is set to [```0] or [```1].
Range:
[`ALO] to [``rH], or [``rL] if [`ALO] is not active. Default: [``rH]
Calibration Offset: Adds or subtracts degrees from the input signal.
Range: -180°F to 180°F/-100°C to 100°C;
or -18.0°F to 18.0°F/-10.0°C to 10.0°C
Default: 0
[`LLO] Low Limit Set Point*
[`LHI] High Limit Set Point*
[`ALO] Alarm Low*
[`AHI] Alarm High*
[`CAL] Calibration Offset
* These parameters may be masked or hidden,
depending on the settings of your controller.
For an explanation of when the parameters
will appear, refer to Table 4.6 below.
‰
Operation Menu
Operation Menu
Figure 4.6 -
The Operation Menu.
[`LLO}
[`LHI}
{`ALO}
{`AHI}
{`CAL}
