WATLOW Series 92 User's Manual
5
Line Voltage
WARNING:
To avoid potential electric shock, use National Electric
Code safety practices when wiring and connecting this
unit to a power source and to electrical sensors or
peripheral devices.
All wiring and fusing must conform to the National
Electric Code and to any locally applicable codes also.
2
3
4
5
6
7
8
9
1
Fuse
L2
L1
Figure 4 - 120 and 240VAC Power Wiring
(determined by your model number)
92X
3
- XXXX - X0XX
(Reset Switch
customer supplied)
Figure 5 - Reset Switch and Remote Setpot Wiring
(determined by your model number)
92
A
X - XXXX - X0XX
120VAC
and
92
B
X -
XXXX - X0XX
208/240VAC
92XX - XXXX -
1
0XX
(Remote Setpot)
10 11 12 13 14 15 16 17
P3
P2
P1
Remote
Setpot
Assembly
N.O.
Momentary
Reset Switch
Green
Black
Red
