18 WATLOW DIN-A-MITE Style C User's Manual
Declaration of Conformity
DIN-A-MITE
®
“C” Power Controller
WATLOW
an
ISO 9001
approved facility since 1996.
1241 Bundy Blvd.
Winona, MN 55987 USA
Declares that the following product:
Designation: DIN-A-MITE “C” Power Control
Model Numbers: DC(1, 2, 3, 8 or 9)(0, 1, 2, 3 or T) – (02, 12, 20, 24, 27, 40, 48 or 60)
(CX, K1, K2, K3, F X , S X ) – (0, H or S)(followed by any 3 numbers or letters.)
X = any number 0 - 9
Classification: Power Control, Installation Catego ry III, Pollution degree 2, IP20
Rated Voltage: 24 to 600 V~ (ac), 50/60 Hz
Meets the essential requirements of the following European Union Directives by using the relevant
standards show below to indicate compliance.
2004/108/EC Electromagnetic Compatibility Directive
EN 61326-1: 2005 Electrical equipment for measurement, control and laboratory use
– EMC requirements (Industrial Immunity, Class A
1,2,4
Emissions)
Not for use in a Class B environment without additional filtering.
EN 61000-4-2:2008 Electrostatic Discharge Immunity
EN 61000-4-3:2006 Radiated Field Immunity 10V/m 80 MHz- 1GHz, 3V/m 1.4GHz-2.7GHz
EN 61000-4-4:2011 Electrical Fast-Transient / Burst Immunity
EN 61000-4-5:2006 Surge Immunity
EN 61000-4-6:2008 Conducted Immunity
EN 61000-4-11:2004 Voltage Dips, Short Interruptions and Voltage Variations
EN 61000-3-2:2005 Harmonic Current Emissions
EN 61000-3-3:2005
EN 61000-3-11:2001 Voltage Fluctuations and Flicker ≤ 16A
Voltage Fluctuations and Flicker ≤ 75A with conditional connection
Notes
1
Use of an external filter is required to comply with conducted emissions limits. See note 4 below.
2
A Line Impedance Stabilization Network (LISN) was used for conducted emissions measurements.
3
To comply with flicker requirements, command signal models FX or SX will require a reduced source
impedance. Cycle time on ON/OFF models CX and K1, K2, K3 may need to be up to 175 seconds at 16A
or have a reduced source impedance.
2006/95/EC Low-Voltage Directive
EN 50178:1997 Electronic equipment for use in power installations.
Per 2002/96/EC W.E.E.E Directive Please Recycle Properly.
These devices contain lead solder and are not RoHS compliant.
They are a Control Device and fall outside the scope of 2002/95/EC Directive.
4 Required External EMI Filters for DIN-A-MITE with More Than 6 Amp Loads. An external ElectroMagnetic
Interference (EMI) filter must be used in conjunction with the DIN-A-MITE for loads in excess of six amperes
(6A) at 150 to 250 KHz. Watlow has verified that a tank filter will suppress EMI created by SCR power
controllers to comply with the conducted emissions limits. For graphic depictions of the filters in a circuit drawing
s
ee section entitled “Required External EMI Filters for DIN-A-MITE with More than 6A Loads”.
®
