mA Process Output
mA Process Output 1 & 2 Procedure
Equipment Required
• 4 1/2 digit digital multimeter
Setup and Calibration
1. Connect the AC voltage L1, L2 and ground to the proper terminals on the
Series 988. See Chapter 2 in the user's manual.
2. For Output #1 calibration: Connect the digital multimeter to terminal
#12 (+) and terminal #14 (-). Set the DMM to read a range of 0 to 20mA.
Connect the leads of the DMM to measure current.
For Output #2 calibration: Connect the digital multimeter to terminal
#15 (+) and terminal #17 (-). Set the DMM to read a range of 0 to 20mA.
Connect the leads of the DMM to measure current.
3. Apply power to the unit and let it warm up for 15 minutes. After warm up put
the unit in the CAL menu. See Page 6.
When performing calibration procedures, always do the Output 1 prompts
(beginning with a “1”) first, then continue on to the Output 2 prompts
(beginning with a “2”). See the Calibration menu on Page 6.
4. At the 1 4 or 2 4 prompt, the multimeter should read approximately 4 mA. Use
the Up or Down keys to adjust the reading on the multimeter for 3.85mA
±
.05mA. Allow the control to stabilize for 10 seconds. Press the Mode key to
enter and advance to the next prompt.
5. At the 1 20 or 2 20 prompt, use the Up or Down keys to adjust the reading on
the multimeter for 20.15mA
±
.05mA. Allow the control to stabilize for 10 sec-
onds. Press the Mode key to enter and advance to the next prompt. To con-
clude the process output calibration, press the Display key.
NOTE:
Any prompt begin-
ning with a “1”
applies to Output 1.
Those beginning
with a “2” apply to
Output 2.
