27
Command: K5PQRC
Response: K5P200CRLF loop 5 proportional gain is 200
To set the integral multiplier:
T(1)M(a)CR T is the time indicator
1 affects all loops
M indicates the multiplier
a is the value from 1 to 3
Command affects all loops.
The integral multiplier sets the range and resolution of the integration time. Values can
be input according to the following table with corresponding resolution:
Multiplier Range Resolution
1 0 to 255 sec 1 sec
2 0 to 510 sec 2 sec
3 0 to 765 sec 3 sec
4 0 to 1020 sec 4 sec
Example:
Command: T1M3CR sets integral multiplier to 3 for all loops
Response: T1M3CRLF
Note: Changing the integral multiplier after setting the integration time will cause
the integration time to change.
To query the integral multiplier:
T(1)MQCR
To set the integration (reset) time:
T(n)I(abcd)CR T is the time indicator
n is the loop number
I is the integral indicator
abcd is the value from 0000 to 1020 sec
The integration range depends on the integral multiplier, see above. [abcd must be
divisible by the integral multiplier]
To query the integration time:
T(n)IQCR
