Chapter 2 Specifications
2-13
Switch
No.
Description ON OFF Notes
1 Used for the system. Reserved Reserved Factory Settings: ON
2 Used for the system. Reserved Reserved Factory Settings: OFF
3 Used for the system. Reserved Reserved Factory Settings: ON
4 Used for the system. Reserved Reserved Factory Settings: OFF
5 Used for the system. Reserved Reserved Factory Settings: OFF
6 Changes Reset SW mode.
Power
button
Reset SW Factory Settings: OFF
7 Used for the system. Reserved Reserved Factory Settings: OFF
8
Changes COM2 (RI <---> +5V).
(enabled only when RS-232C
mode)
+5V Output RI Factory Settings: OFF
9
Changes a Master/Slave setting for
Primary CF Card Interface.
Slave Master
The factory settings depend
on your selected built-in
accessory.
10 Used for the system. Reserved Reserved Factory Settings: OFF
Table 1) System Set Switches
