PS-3000B Series Hardware Manual
2-2
2.1 PS3000-BA
2.1.1 General Specifications
„ Electrical Specifications
„ Environmental Specifications
Power
Supply
Input Voltage AC100/240V
Rated Voltage AC85 to 265V
Rated Frequency 50/60Hz
Allowable Voltage
Drop
1 cycle or less (Voltage drop interval must be 1s or more.)
Power Consumption 120VA or less
Rush current
At AC100V (normal temperature): 30A or less
At AC240V (normal temperature): 50A or less
Voltage Endurance
AC1500V 20mA for 1minute
(between charging and FG terminals)
Insulation Resistance DC500V 10M
Ω (min.) (between charging and FG terminals)
Physical
Surrounding Air
Temperature 0 to 50°C: without HDD
5 to 50°C: with HDD
Storage Temperature
−20 to +60°C
Ambient Humidity
10 to 90%RH (Not condensing, wet bulb temperature: 39°C or
less. Wet bulb temperature with HDD: 29°C or less.)
Storage Humidity
10 to 90%RH (Not condensing, wet bulb temperature: 39°C or
less.)
Dust Free of dust
Pollution Degree For use in Pollution Degree 2 environment
Corrosive gas Free of corrosive gases
Atmosphere
(Using height)
800 to 1114hPa (-300 to 2,000 meters above sea-level and below)
Mechanical
Vibration Resistance
IEC61131-2 compliant
5 to 9Hz single-amplitude 3.5mm
9 to 150Hz constant-accelerated velocity 9.8m/s
2
X, Y, Z directions for 10 cycle (100 minute)
4.9m/s
2
(10 to 25Hz X,Y,Z directions for 30 minute)
El
ect
ri
c
al Noise Immunity
Noise Voltage: 1500V
P-P
Pulse Duration: 50ns, 500ns, 1µs
Rise Time: 1ns
(via noise simulator)
Electrostatic Discharge
Immunity
6kV (complies with EN 61000-4-2 Level 3)
Noise Immunity
(Fast Transient Burst Noise) Power supply line: 2kV (IEC61000-4-4)
COM port: 1kV (IEC61000-4-4)
