PS-4700 Series (Atom Z510 Pre-installed Model) User Manual
81
3 Untighten the cable clamp:
4 Connect the USB cable to the USB connector:
NOTE:
z When using two USB ports, be sure to first connect one USB cable to the lower
USB connector, and then connect the second USB cable to the upper USB
connector.
z When using only one of the USB ports, be sure to use the lower USB connector.
This allows you to easily attach the second USB cable in the future.
5 Pass the USB cable into the cable clamp and securely tighten the cable clamp:
NOTE: Be sure to respect the bending requirements for your USB cable.
Step Action
