HMI5000 Series Installation Guide
1010-1005 Rev 05 www.maplesystems.com
STEPS:
1. Prepare the clamps for the HMI by inserting the screws into the
clamp as shown above. Position the screws so that the ends don’t
protrude through the clamp’s hole.
2. Set the HMI in the panel cutout and hold it in place until all
clamps are in position.
3. Tighten the screw clamps in an even pattern until all are
uniformly snug.
Caution: Do not over-tighten the screws beyond snugness or
you may damage the housing or warp the overlay.
Mounting Clamp Placement
Model
Left
Side
Right
Side
Top
Bottom
Clamps
Provided
with Unit
HMI5043N/T
2
2
0
0
4
HMI5056N
1
1
2
2
4
HMI5070NH/TH
2
2
2
0
4
HMI5100N/T,
HMI5104TH,
HMI5104XH
0
0
3
2
5
HMI5121X
2
2
3
3
9
HMI5150X
2
2
3
3
10
HMI5070ETH
1
1
2
2
6
REINSTALLATION: If, at anytime, you are required to reinstall an
HMI into a panel, be aware that the gasket will take a ‘set’ to the panel
and may no longer provide an adequate NEMA 4 seal Therefore, for best
results, we recommend that you replace the gasket if reinstallation is
required.
