HMI5000HD Installation Guide
1010-1019 Rev 01 www.maplesystems.com
SW1
SW2
Mode
OFF
OFF
Normal Operation
ON
OFF
Hide System Setting Toolbar
OFF
ON
Boot Loader mode
ON
ON
Restore Factory Settings
Hide System Toolbar: Hides the arrow in the bottom-right corner of the
screen that accesses the System Toolbar (same as “Hide System Toolbar”
in System Parameters and LB9020).
Boot Loader mode: This mode forces the HMI to not execute the
project. This mode is used when replacing or reinstalling the operating
system. Contact Maple Systems for more information.
Restore Factory Settings: Erase project data and restore factory
settings such as IP settings and passwords.
Fusing Requirements
If the display does not come on within two seconds of power up, remove
power. An internal fuse will prevent damage if the polarity of the DC
power is incorrect. Check wiring to insure proper connections and try to
power up again.
