50 Installation and User’s Guide
1 Introducing the Agilent 85225F Performance Modeling System
Table 10 Front Panel System Connections
Component Information Connection Information
Designator Model
Number Description Connector
Type From
Instrument Connector
Labeled To Connector
Labeled On
Instrument
1 16494A
Option 002 Triaxial cable Triax BNC 41501B
HPSMU FORCE DC FORCE 11612V K11
2 16494A
Option 002 Triaxial cable Triax BNC 41501B
HPSMU SENSE DC SENSE 11612V K11
3 16494A
Option 002 Triaxial cable Triax BNC 4156C
HRSMU1 FORCE DC FORCE 11612V K21
4 16494A
Option 002 Triaxial cable Triax BNC 4156C
HRSMU1 SENSE DC SENSE 11612V K21
5 16493L
Option 002 Triaxial
GNDU cable Triax BNC 41501B GNDU GNDU 11612V K21
6 85133F Flexible test
port cable 2.4 mm E8364B PORT 1 RF IN 11612V K11
7 85133F Flexible test
port cable 2.4 mm E8364B PORT 2 RF IN 11612V K21
8 16048D LCR meter
test cable BNC 4284A UNKNOWN Test fixture
or probe
station
9 8120-1839 Coaxial cable BNC 35670A CH1 Test fixture
or probe
station
