38 Installation and User’s Guide
1 Introducing the Agilent 85225F Performance Modeling System
Table 8 Rear Panel System Connections
Component Information Connection Information
Designator Model
Number Description Connector
Type From
Instrument Connector
Labeled To Connector
Labeled On
Instrument
1 16494A
Option 002 Triaxial cable Triax BNC 4156C
HRSMU1 FORCE DC FORCE 11612V K11
2 16494A
Option 002 Triaxial cable Triax BNC 4156C
HRSMU1 SENSE DC SENSE 11612V K11
3 16494A
Option 002 Triaxial cable Triax BNC 4156C
HRSMU2 FORCE DC FORCE 11612V K21
4 16494A
Option 002 Triaxial cable Triax BNC 4156C
HRSMU2 SENSE DC SENSE 11612V K21
5 16494A
Option 002 Triaxial cable Triax BNC 4156C
HRSMU3 FORCE GNDU 11612V K21
6 10833D GPIB cable GPIB 4156C GPIB GPIB 4284A
7 10833D GPIB cable GPIB 4284A GPIB GPIB E8364B
8 10833C GPIB cable GPIB E8364B GPIB GPIB Controller
