Understanding the Bias Networks F
Installation and User’s Guide 139
Characteristics
Table 20 11612V Option K11/K21 Bias Network Characteristics
Parameter 11612V Option K11 11612V Option K21
Test port Port 1 Port 2
Frequency range 45 MHz to 50 GHz 45 MHz to 50 GHz
Test port connector 2.4 mm 2.4 mm
Maximum current 0.5 amps 0.5 amps
Maximum voltage 40 volts 40 volts
Maximum RF power 2 watts (+33 dBm) 2 watts (+33 dBm)
Height 50 mm (2 inches) 50 mm (2 inches)
Width 105 mm (3.5 inches) 105 mm (3.5 inches)
Depth 70 mm (2.75 inches) 70 mm (2.75 inches)
Net weight 370 grams (0.8 pounds) 370 grams (0.8 pounds)
C A U T I O N
Do not exceed the maximum ratings of the bias networks. Failure to
comply can result in severe damage.
