The Low Leakage Switch Mainframe
The Agilent E5250A is used for precise parametric test. It improves
measurement efficiency by eliminating the need to manually change the
probe positions on a manual probe station. The E5250A is used to route
signals from the 4156C and the 4284A to the probe card cable, and on to
probe card and probe station.
Table 9 Rear Panel Connections, including Low Leakage Switch Mainframe
Component Information Connection Information
Designator Model
Number Description Connector
Type From
Instrument Connector
Labeled To Connector
Labeled On
Instrument
1 16494A
Option 002 Triaxial cable Triax BNC 4156C
HRSMU1 SENSE SMU
INPUT 2 E5250A
2 16494A
Option 002 Triaxial cable Triax BNC 4156C
HRSMU1 FORCE SMU
INPUT 1
E5250A
3 16494A
Option 002 Triaxial cable Triax BNC 4156C
HRSMU2 FORCE SMU
INPUT 3 E5250A
4 16494A
Option 002 Triaxial cable Triax BNC 4156C
HRSMU2 SENSE SMU
INPUT 4 E5250A
5 16048D LCR meter
test cable BNC 4284A UNKNOWN T1 & T2 (CV1
& CV2) E5250A
6 10833D GPIB cable GPIB 4156C GPIB GPIB 4284A
7 10833D GPIB cable GPIB 4284A GPIB GPIB E8364B
8 10833D GPIB cable GPIB E8364B GPIB GPIB E5250A
9 10833C GPIB cable GPIB E5250A GPIB GPIB Controller
T1 1250-2405 BNC tee BNC 4284A HIpot/HIcur CV1 E5250A
T2 1250-2405 BNC tee BNC 4284A LOpot/LOcur CV2 E5250A
