Ramsey Winch RPH-12000 - Manual (Page 21)

PARTS LIST RPH 12,000 WITH AIR-CYLINDER CLUTCH SHIFTER
ITEM QTY. PART NO. DESCRIPTION
1
1 234171 DRUM ASS'Y.
2 1 236020 LIGHT ASSEMBLY
3 1 276053 SHIFTER ASS'Y.-AIR CYLINDER
4 1 306042 PISTON-BRAKE
5 1 312529 BRACKET-LIGHT
6 1 338300 END BEARING-MOTOR
7 1 338301 END BEARING-GEAR HOUSING
8 1 338302 HOUSING-BRAKE
9 4 346045 PIN-BRAKE
10 1 357504 SHAFT-INPUT/SUN GEAR
11 2 395172 TIE PLATE
12 1 402120 BEARING-GEAR HSG.
13 1 402121 BEARING-MTR. END BEARING
14 1 412084 BUSHING-DRUM (MTR. END)
15 1 412085 BUSHING-DRUM (G.HSG. END)
16 2 414036 CAPSCREW 1/4-20NC X 1/2 LG.
17 6 414303 CAPSCREW 3/8-16NC X 2-1/2 LG. HX.HD., GR. 5 PLTD.
18 2 414948 CAPSCREW 1/2-13NC X 1-1/4 LG. SOC.HD.
19 8 414581 CAPSCREW 1/2-13NC X 3/4 LG. HX.HD. GR.5 PLTD.
20 4 414159 CAPSCREW 5/16-18NC X 1-1/2 LG. HX. HD. GR 5 Z/P
21 1 414926 SETSCREW-3/8-16NC X 1 LG., SOCKET, NYLON
22 1 416016 SETSCREW-1/4-20NC X 1/4 LG., HX. SOC. HD.
23 1 418036 NUT 3/8-16NC HEX. JAM
24 2 418218 LOCKWASHER-1/2 ID MED. SECT.
25 1 431015 COUPLING-MOTOR
26 2 432018 FITTING-7/16 ELBOW
27 NOT USED
28 4 438022 DISC-BRAKE
29 1 442220 GASKET-BRAKE
30 1 442223 GASKET-MOTOR
31 1 444085 GEAR-RING
32 1 456038 FITTING-VENT
33 1 458090 MOTOR-HYDRAULIC
34 1 462046 O-RING (DRUM)
35 1 462056 O-RING
36 1 462057 O-RING
37 1 462058 O-RING
38 1 462059 O-RING BACKUP
39 1 462060 O-RING BACKUP
40 5 474111 PLATE-SEPARATOR
41 1 482013 BOOT
42 1 482045 BOOT
43 1 486080 SEAL-GEAR HSG.
44 2 488007 SHIM
45 1 490037 SNAP RING
46 6 494110 SPRING-BRAKE
47 4 494112 SPRING
48 1 504021 SWITCH
49 1 509009 TUBE ASSEMBLY
50 1 516013 VALVE-MOTOR CONTROL
51 1 518047 THRUST WASHER
52 1 518052 THRUST WASHER
53 4 418163 LOCKWASHER – 5/16 MED SECT Z/P
