E-7 TROUBLESHOOTING E-7
MAXsa™ 10 CONTROLLER
Observe all Safety Guidelines detailed throughout this manual
If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact your
Local Lincoln Authorized Field Service Facility for technical troubleshooting assistance before you proceed.
CAUTION
PROBLEMS
(SyMPTOMS)
POSSIBLE
CAUSE
RECOMMENDED
COURSE OF ACTION
The feeder does not power up - no
display, no feed. 1. The Power Wave power source is
OFF. Turn ON the Power Wave
source.
2. The circuit breaker for the wire
feeder on power source has
tripped. Reset the circuit break-
ers.
3. The control cable may be loose
or damaged. Tighten, repair or
replace the control cable.
4. The power switch is damaged.
Replace the power switch.
If all recommended possible areas of
misadjustment have been checked
and the problem persists, Contact
your local Lincoln Authorized Field
Service Facility.
Typical User Interface 3 digit error codes (not blinked on the status LED).
Error
Code
283
285
612
Source
User Interface
UI Text
(Varies based on the
error type and who
caused the error)
N/A
{" Phase Gen Init "},
{"Duplicate Arc # "},
{" Mult Lead Arcs "},
{" Missing an Arc "},
{" Too Many Arcs "},
{"Missing Lead Arc"},
{" Missing an Arc "}
Reason
Internal Error. Collect all displayed values and contact
Lincoln Electric Service Department.
UI memory could not be restored. Contact Lincoln
Electric Service Department for further support.
1 = Initializing Phase Generator
2 = Duplicate Arc #'s found
3 = Mult Lead Arcs found
4 = Missing a Trail Arc
5 = Too Many Arcs
6 = Missing Lead Arc
7 = Trail Arc dropped communication with Lead Arc
OUTPUT PROBLEMS
