4.5.9 Install the CPU Card

CAUTION

Before a CPU card is inserted into the backplane, make sure the CPU card has

been correctly prepared and that all the CPU card jumper settings are

configured correctly. For CPU card component installation procedures, please

refer to the user manual that came with the CPU card.

CAUTION

Depending on the location of the CPU card, the disk drive ribbon cable

connectors and other peripheral device cable connectors may have to be

connected to the CPU card before it can be installed.

To install a CPU card onto the backplane, follow the instructions below:

Step 1:

Remove the slot bracket from the chassis rear panel by removing the slot cover

retention screw (Figure 4-12).
