EC-1040GB Workstation
Page 14
3.1 EC-1040GB Specifications
Table 3-1 shows the EC-1040GB specifications.
LCD Type 6.5" TFT
Input Interface VGA
Max. Resolution 640 x 480
Backlight MTBF 50,000 Hrs
Contrast 600:1
LCD Color 262K
Brightness (cd/m2) 800
Chassis Heavy-duty steel
View Angle (H / V) 160° / 140°
OSD function Yes
Mounting 19” Rack Mount
Rack Height 4U
Keyboard 88 Keys – Slim Size (Keyboard models only)
Touch Pad Yes – with 2 buttons
Cooling Fan 2 – 8cm
Expansion Slots
14 for EC-1040GB
7 for EC-1040GBATX
Dimensions (WxHxD) (mm) 431 x 177 x 480
Weight (Gross/Net) 15.3kg / 28.8kg
Color Black (Pantone Black C)
Vibration
5 ~ 17 Hz, 0.1” double amplitude displacement
17 ~ 640 Hz, 1.5G acceleration peak to peak
Shock 10G acceleration peak to peak (11ms)
Humidity 5 ~ 95%, relative
Operating Temperature 0 ~ 50°C
Table 3-1: EC-1040GB Specifications
