RPC-6022GW Rackmount LCD Workstation

Page 40

Step 1:

WARNING:

Failure to follow the installation procedures outlined in this section may

cause severe damage to the RPC-6022GW Rackmount LCD

Workstation. Please follow the installation instructions carefully.

4.5.1 Remove the Top Cover

The top cover is secured to the RPC-6022GW Rackmount LCD Workstation with six

screws (three each on the left and right panels). To remove the top cover, please follow

the steps below.

Remove the six top cover retention screws (three each on the left and right

panels). (See Figure 4-1)

Figure 4-1: Top Cover Retention Screws
