4.4.3 Installation Steps

Complete the following steps to properly install the workstation:

Open the top cover.

Remove the CPU card clamp.

Remove the disk drive brackets.

Install the disk drives.

Reinstall the disk drive bracket with the installed disk drives.

Install the backplane.

Install the CPU card.

Install the PCI or ISA expansion cards (optional).

Connect all required cables.

Reinstall the CPU card clamp.

Close the top cover.

Mount the workstation.

Step 0:

4.5 Installing Components into the RPC-6022GW

NOTE:

This section gives a generic description of the component installation

process for the RPC-6022GW Rackmount LCD Workstation.
