Specification
Description
LCD Size
8"
Max. Resolution
800 x 600
Contrast Ratio
500:1
Brightness (cd/m
2
)
250
LCD Color
262K
Pixel Pitch (H x V) (mm) 0.2025 x 0.2025
Viewing Angle (H-V)
140°/130°
Backlight MTBF
30000 hours (LED)
SBC Model
AFLMB-945GSE-N270
CPU
1.6 GHz Intel® Atom™ N270
Chipset
Intel® 945GSE + ICH7M
Memory
One 1.0 GB 533 MHz DDR2 SDRAM SO-DIMM pre-installed (supports up to
2.0 GB 533/400 MHz DDR2 SDRAM)
SSD
CF Type II slot
Watchdog Timer
Software Programmable supports 1 sec. ~ 255 sec. system reset
Audio
AMP 1.5 W + AMP 1.5 W (built-in stereo speakers)
Camera
300 K pixel webcam
Expansion
1 x PCIe mini card (wireless LAN 802.11 b/g/n module)
1 x Optional Bluetooth module (USB interface, Bluetooth v 2.0)
Construction Material
ABS + PC plastic front frame
Mounting
Panel, Wall, Stand, Arm (VESA 75 mm x 75 mm)
Dimensions (W x H x D) 234 mm x 177 mm x 43 mm
Operation Temperature
-10ºC ~ 50ºC
Storage Temperature
-20ºC ~ 60ºC
Net weight
1.8 kg
IP level (front panel)
IP 64
EMC
CE, FCC and CCC
Safety
CB
Touch Screen
AFL-F08A-N270/R: 5-wire analog resistive type touch window
AFL-F08A-N270/PC: Multi-touch projected capacitive touch screen (USB)
Power Adapter
36 W power adapter
Input: 100 V AC ~ 240 V AC @ 50 Hz / 60 Hz
Output: 12 V DC
