Figure 3-17: chassis support screws – IEI Integration AFL-19i-HM55 v1.01 User Manual

Page 52

background image

AFL-HM55 Series Panel PC

Page 40

NOTE:

In the diagram below the bracket is already installed on the wall.

Figure 3-17: Chassis Support Screws

Secure the panel PC by fastening the retention screw of the wall-mounting bracket.

(Figure 3-18).
