UPC-12A/GM45 Panel PC
Page 86
6.3.7 Power Configuration
The Power menu (BIOS Menu 11) allows the advanced power management options to be
configured.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
Power Supply Status [AT]
ÅÆ Select
Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 12: Power Configuration
Î Power Supply Mode [AT]
Use the Power Supply Mode BIOS option to select the power supply that is connected to
the system.
Î
AT D EFAULT
An AT power supply is connected to the system
Î
ATX An ATX power supply is connected to the system
6.4 PCI/PnP
Use the PCI/PnP menu (
607H607H607H607H606H606H606H608H
BIOS Menu 13 ) to configure advanced PCI and PnP settings.
WARNING!
Setting wrong values for the BIOS selections in the PCIPnP BIOS
menu may cause the system to malfunction.
