UPC-12A/GM45 Panel PC
Page 23
2.8.5 Power Mode
The system can be run in the AT power mode or the ATX power mode. The power mode
switch is shown in
535H535H535H535H535H535H535H537H
Figure 2-14 .
Figure 2-14: AT/ATX Mode Switch
The UPC-12A/GM45 is also has an UPS/Battery mode switch shown in
536H536H536H536H536H536H536H538H
Figure 2-15 .
Figure 2-15: UPS/Battery Mode Switch
