UPC-12A/GM45 Panel PC
Page 3
1.1.1 Model Variations
The model variations of UPC-12A/GM45 series are listed in
523H523H523H523H523H523H523H525H
Table 1-1 .
UPC-12A/GM45 CPU Brightness Memory Wireless
-CM5/R/1G-R21 2GHz Intel® Celeron® M 575 500cd/m 2 1GB DDR2 Yes
-P84/R/2G-R21 2.26GHz Intel® Core™2 Duo P8400 500cd/m 2 2GB DDR2 Yes
-T94/R/2G-R21 2.53GHz Intel® Core™2 Duo T9400 500cd/m 2 2GB DDR2 Yes
AFL-12AH/GM45 CPU Brightness Memory Wireless
-CM5/-R/1G-R20 2GHz Intel® Celeron® M 575 1300cd/m 2 1GB DDR2 Yes
-P84/R/2G-R20 2.26GHz Intel® Core™2 Duo P8400 1300cd/m 2 2GB DDR2 Yes
-T94/R/2G-R20 2.53GHz Intel® Core™2 Duo T9400 1300cd/m 2 2GB DDR2 Yes
Table 1-1: Model Variations
1.1.2 Features
All the UPC-12A/GM45 models feature the following:
ƒ Intel® Core™2 Duo or Intel® Celeron® M processor
ƒ Intel® GM45 chipset
ƒ DDR2 SDRAM preinstalled
ƒ Three standard RS-232 connectors and one RS-232/422/485 connector
ƒ Six standard USB 2.0 ports
ƒ Watchdog timer that triggers a system reset if the system hangs for some
reasons
ƒ Remotely monitor system power status through smart battery utility
ƒ Built-in two stereo speakers
ƒ IP 65 compliant front panel
ƒ AT or ATX power mode
ƒ Battery backup power support
ƒ Second displays support
ƒ Touch screen
ƒ RoHS compliance
ƒ 802.11 b/g/n PCIe wireless module with PIFA antennas
