ƒ Only handle the edges of the PCB:- When handling the PCB, hold the PCB
by the edges.
5.3 Turn off the Power
WARNING:
Failing to turn off the system before opening it can cause permanent
damage to the system and serious or fatal injury to the user.
Before any maintenance procedures are carried out on the system, make sure the system
is turned off.
5.4 Replacing Components
5.4.1 Hard Disk Drive Replacement
If the HDD fails, please follow the steps below:
Step 1: Follow all anti-static procedures . See Section
575H575H575H575H575H575H575H577H
5.2 .
Step 2: Turn off the power . See Section
576H576H576H576H576H576H576H578H
5.3 .
Step 3: Follow the steps described in Section
577H577H577H577H577H577H577H579H
4.6 to replace the HDD. Step 0:
5.4.2 CF Card Replacement
The UPC-12A/GM45 has one CF Type II slot. To replace the CF card, follow the
instructions below.
Step 1: Follow all anti-static procedures . See Section
578H578H578H578H578H578H578H580H
5.2 .
Step 2: Turn off the power . See Section
579H579H579H579H579H579H579H581H
5.3 .
Step 3: Follow the steps described in Section
580H580H580H580H580H580H580H582H
4.5 to replace the CF card.
