UPC-12A/GM45 Panel PC
Page 14
2.2 Intel
®
Processor Support
An Intel® processor is installed in the system. Please refer to
527H527H527H527H527H527H527H529H
Table 1-1 for model and
CPU variations. The processor specifications are listed below.
Processor Number 575 P8400 T9400
CPU Speed 2 GHz 2.26 GHz 2.53 GHz
Bus Speed 667 MHz 1066 MHz 1066 MHz
Bus/Core Ratio 12.0 8.5 9.4
L2 Cache Size 1 MB 3 MB 6 MB
L2 Cache Speed 2 GHz 2.26 GHz 2.53 GHz
Technology 65 nm 45 nm 45 nm
Table 2-1: UPC-12A/GM45 Series CPU Specifications
The processor is protected by the dust-proof heat sink shown in
528H528H528H528H528H528H528H530H
Figure 2-2 below.
Figure 2-2: CPU and Chipsets Heat Sink
