4.4.1 NorthBridge Configuration
Use the NorthBridge Configuration menu (BIOS Menu 16) to configure the Northbridge
chipset.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Chipset
NorthBridge Configuration
Memory Information
Memory Frequency
1333 Mhz
Total Memory 2048 MB (DDR3)
Memory Slot Not Present
Onboard Memory 2048 MB (DDR3)
> Graphics Configuration
Config Graphics
Settings.
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 16: Northbridge Chipset Configuration
4.4.1.1 Graphics Configuration
Use the Graphics Configuration menu (BIOS Menu 17) to configure the graphics
options.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Chipset
Graphics Configuration
DVMT Pre-Allocated
[64M]
DVMT Total Gfx Mem [MAX]
Boot Display Device
[CRT]
Select DVMT 5.0
Pre-Allocated (Fixed)
Graphics Memory size
used by the Internal
Graphics Device.
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 17: Graphics Configuration
