TANK-700 Embedded System
Page 4
Specifications
I/O and Indicators
Ethernet 2 x Combo (SFP Fiber/RJ-45) Gigabit LAN
RS-232 4 x DB-9 serial ports on rear panel
2 x RJ-45 serial ports with isolation on front panel
RS-422/RS-485 2 x RJ-45 serial ports with isolation on front panel
USB Interfaces 2 x USB 3.0 ports on front panel
4 x USB 2.0 ports on rear panel
Display 1 x VGA port (supports resolution up to 2048 x 1536 @ 75Hz)
1 x HDMI port (supports resolution up to 1920 x 1200 @ 60Hz)
Audio Connector 1 x Line-out port
1 x Mic-in port
CAN-bus
1 x Phoenix terminal block on front panel
Audio/Video Capture
Optional 4-channel audio/video input PCIe Mini card (up to two
cards)
Digital I/O 1 x DIO port (8 bits)
LED Indicators AT power mode LED
ATX power mode LED
CAN-bus LED
CPU temperature alert LED
HDD LED
LAN 1 LED
LAN 2 LED
Power 1 LED
Power 2 LED
SFP Fiber 1 LED
SFP Fiber 2 LED
Wireless LED
Storage
SATA
SATA 6Gb/s with 2.5” HDD/SSD support
