4.3.6 Second Super IO Configuration
Use the F81216 Second Super IO Configuration menu (BIOS Menu 8) to set or change
the configurations for the serial ports.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
F81216 Second Super IO Configuration
Second Super IO Chip
Finteck F81216
> Serial Port 7 Configuration
> Serial Port 8 Configuration
Set Parameters of Serial
Port 7
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 8: F81216 Second Super IO Configuration
4.3.6.1 Serial Port n Configuration
Use the Serial Port n Configuration menu (BIOS Menu 9) to configure the serial port n.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
Serial Port n Configuration
Serial Port [Enabled]
Device Settings IO=2C0h; IRQ=11
Change Settings
[Auto]
Device Mode [Normal]
Enable or Disable Serial
Port (COM)
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 9: Serial Port n Configuration Menu
