IEI Integration TANK-101B-D525_N455 v1.00 - Manual (Page 14)

TANK-101B/BW Em b e d d e d S ys te m
P a g e 4
S p e c ific a tio n s
US B 4 x USB 2.0 ports
Dis p la y 1 x VGA port
Re s o lu tio n Up to 2048x1536 @ 60 Hz (D525 model)
Up to 1400x1050 @ 60 Hz (N455 model)
Au d io 1 x Line-out port
1 x Mic-in port
CAN-b u s 2 x CAN-bus ports with isolation
Exp a n s io n s One PCIe Mini card slot (reserved for wireless module)
S to ra g e One 2.5” SATA HDD supported
One CompactFlash® socket
P o we r S u p p ly 9V~36V DC input
P o we r Co n s u m p tio n 12 W @ 1.85A
Mo u n tin g Wall mount
Op e ra tin g Te m p e ra tu re -20
°C~60°C (D525 model with CompactFlash®/SSD*)
-20
°C~70°C (N455 model with CompactFlash®/SSD*)
-10
°C~50°C (with Wi-Fi)
*Ambient air speed per IEC-68-2-2 standard
Op e ra tin g S h o c k Half-sine wave shock 3G; 11ms; 3 shocks per axis
Op e ra tin g Vib ra tio n MIL-STD-810F 514.5C-1 (HDD)
MIL-STD-810F 514.5C-2 (CF)
Co lo r Cool Gray + Blue
Ch a s s is Co n s tru c tio n Aluminum alloy with heavy duty metal
We ig h t (Ne t/Gro s s ) 2.1 kg/3.9 kg
P h ys ic a l Dim e n s io n s 248 mm x 153 mm x 44 mm (W x D x H)
Table 1-2: Technical Specifications
