KINO-9453 Mini-ITX Motherboard
2.6.3 Intel
®
ICH7M IDE Interface
The integrated IDE interface on the ICH7M southbridge supports two IDE hard disks and
ATAPI devices. PIO IDE transfers up to 16MB/s and Ultra ATA transfers of 100MB/s. The
integrated IDE interface is able to support the following IDE HDDs:
Ultra ATA/100, with data transfer rates up to 100MB/s
Ultra ATA/66, with data transfer rates up to 66MB/s
Ultra ATA/33, with data transfer rates up to 33MB/s
Specification Ultra ATA/100 Ultra ATA/66 Ultra ATA/100
IDE devices 2 2 2
PIO Mode 0 – 4 0 – 4 0 – 4
PIO Max Transfer Rate 16.6 MB/s 16.6 MB/s 16.6 MB/s
DMA/UDMA designation UDMA 3 - 4 UDMA 3 – 4 UDMA 2
DMA/UDMA Max Transfer 100MB/s 66MB/s 33MB/s
Controller Interface 5V 5V 5V
Table 2-3: Supported HDD Specifications
2.6.4 Intel
®
ICH7M Low Pin Count (LPC) Interface
The ICH7M LPC interface complies with the LPC 1.1 specifications. The LPC bus from the
ICH6 is connected to the following components:
BIOS chipset
Super I/O chipset
2.6.5 Intel
®
ICH7M PCI Interface
The PCI interface on the ICH7M is compliant with the PCI Revision 2.3 implementation.
Some of the features of the PCI interface are listed below.
PCI Revision 2.3 compliant
