KINO-9453 Mini-ITX Motherboard

Family

sSpec# CPU Speed Processor # Bus Speed Mfg Tech Stepping Cache Size

SL8VT

2 GHz

T2500

667 MHz

65 nm

2 MB

Core™ Duo

SL9DN

1.66 GHz

T2300E

667 MHz

65 nm

2 MB

Core™ Solo

SL92X

1.83 GHz

T1400

667 MHz

65 nm

2 MB

Table 2-2: Supported Processors

2.5 Intel

945GM Northbridge Chipset

2.5.1 Intel

945GM Overview

The Intel

945GM northbridge chipset has the Generation 3.1 Intel Integrated Graphics

Engine and the Intel

Graphics Media Accelerator 950 (Intel

GMA 950). The integrated

graphics and memory controller hub (GMCH) facilitates the flow of information primarily

between the following four interfaces:

Front Side Bus (FSB)

System Memory Interface

Graphics Interface

Direct Media Interface (DMI)

2.5.2 Intel

945GM Memory Support

WARNING:

Only DDR2 memory module can be installed on the KINO-9453. Do not

install DDR memory modules. If a DDR memory module is installed on

the KINO-9453, the KINO-9453 may be irreparably damaged.

The Intel

945GM northbridge chipset on the NANO-945GM supports two DDR2 240-pin

DIMMs with the following features:

Two 240-pin DIMMs
