A-2 Specifications
1760-L12BWB
8 (24V dc)
4 (relay)
24V dc
Yes
Yes
2 (0 to 10V dc)
1760-L12BWB-NC
(1)
No
Yes
1760-L12BWB-ND
(2)
Yes
No
1760-L12BBB
4 (MOSFET)
Yes
Yes
2 (0 to 10V dc)
1760-L12BBB-ND
Yes
No
1760-L12NWA
8 (24V ac)
4 (relay)
24V ac
Yes
Yes
1760-L12NWA-ND
Yes
No
1760-L12DWD
8 (12V dc)
12V dc
Yes
Yes
1760-L12DWD-ND
Yes
No
1760-L18BWB-EX
(3)
12 (24V dc)
6 (relay)
24V dc
Yes
Yes
1760-L18BWB-EXND
(2)(3)
6 (relay)
Yes
No
2 (0 to 10V dc)
1760-L20BBB-EX
(3)
8 (MOSFET)
Yes
Yes
4 (0 to 10V dc)
1760-L20BBB-EXND
(2)(3)
8 (MOSFET)
Yes
No
1760-L18DWD-EX
(3)
12 (12V dc)
6 (relay)
12V dc
Yes
Yes
1760-L18DWD-EXND
(2)(3)
6 (relay)
12V dc
Yes
No
1760-L18NWA-EX
(3)
12 (24V ac)
6 (relay)
24V ac
Yes
Yes
4 (0 to 10V dc)
1760-L18NWA-EXND
(2)(3)
12 (24V ac)
6 (relay)
Yes
No
(1) NC = no real time clock
(2) ND = no display
(3) EX = suitable for use with expansion modules
Catalog Number
Inputs
Outputs
Line Power
Real Time
Clock
Display and
Keypad
Analog
