2-14 Drawing a Circuit with Pico
With random switching, the relay contact switches randomly at any
time up to the specified time value (shown shaded in figure).
?
Trigger
Reset
on
on
on
t t
Timing Relay with Off-Delay, with and without
Random Switching
Timer Output
t t
Timing Relay, Single Pulse
on
on
on
Output
Reset
Trigger
