XLT XD-9005B User Manual

Page 90

Text mode
Original mode

background image

Technical Support US: 888-443-2751

Technical Support INTL: 316-943-2751

90

OVEN SCHEMATIC - WORLD 380 VAC

2440-EL, 3240-EL World 380 VAC
