12
OVEN ELECTRICAL REQUIREMENTS
FOR EACH OVEN:
A separate circuit breaker must be provided for each oven deck.
Electrical connections must be accessible when the ovens are in the installed position.
Electrical connections must meet all local code requirements.
Ensure ovens are grounded per local codes.
Incoming Power Connection Point
Control Box Rear - Standard
Earth Ground Lug
Ground Lug
Control Box Rear - World
Incoming Power Connection Point
Ground Lug
Volts AC
Amps
Hertz Volts AC Amps
Hertz
Phase
KW
1832
208/240
44/38
24
16
1855
208/240/480 88/77/38
48
32
2440
208/240/480 75/65/33
41
27
3240
208/240/480 75/65/33
41
27
3255
208/240/480 88/77/38
48
32
3855
208/240/480 88/77/38
48
32
60
380
50
3
4 Wire Service - L1, L2, L3
5 Wire Service - L1, L2, L3
N +2 Grounds (per oven)
+1 Ground (per oven)
Electric Oven Electrical Requirements
Per EACH Oven
Oven
Model
STANDARD
WORLD
ALL
