42
AVI HOOD ELECTRICAL CONNECTIONS
VFD Control Box - Standard w/Fire Suppression
VFD Control Box - World w/Fire Suppression
MUA Damper Relay (R6)
MUA Damper Relay (R5)
MUA Damper Relay (R4)
Terminal Strip
Circuit Breaker
VFD Controller
Cooling Fan Relay (R1)
Fire Suppression Relay, Exhaust Fan (R2)
Hood Lights Relay (R3)
Exhaust Fan Fire Suppression Relay (R4)
Transformer
Terminal Strip
Circuit Breaker
VFD Controller
Hood Lights Relay (R3)
Cooling Fan Relay (R1)
Air proving Circuit Relay (R2)
