52 avi hood electrical connections – XLT XD-9005B User Manual
Page 52

Technical Support US: 888-443-2751
Technical Support INTL: 316-943-2751
52
AVI HOOD ELECTRICAL CONNECTIONS
MUA Damper Relays - Multiple Output - Standard Voltage & Frequency
Some wiring removed for clarity. See schematic for details.
Supply from Breaker Panel
10 Amperes Maximum
TS 1
Neutral
TS 2
R6
A1
A2
Power
In
Power
Out
A1
A2
Power
In
Power
Out
A1
A2
Power
In
Power
Out
R5
R4
MUA Unit Relay
Customer Supplied
MUA Unit Relay
Customer Supplied
MUA Unit Relay
Customer Supplied
