HydroTHerapy
options for Whitehall Whirlpools
-HR Head Rest, Adjustable
This head rest is used to support the patient’s
head during treatment. It is made from
stainless steel tubing with a cover.
USAGE: Lo-boy whirlpools
-MXT1 (15 GPM), -MXT2 (25 GPM) Thermostatic Mixing Valve
These valves are designed to control the mixing of hot and cold
water and deliver it at a constant, pre-set temperature. The valve
is equipped with a union end, loose key, angle stop, check valves
with built-in strainers and vacuum breaker. Control valve is set
to deliver water at temperatures up to 115 degrees Fahrenheit.
Failure of the cold water supply will cause the hot water supply to
close, eliminating any possibility of scalding.
USAGE: All whirlpools
-MXWH Washout Hose Attachment
This option, when installed on the discharge
side of the Thermostatic Mixing Valve (-MXT),
aids in tank clean up. It consists of a tee fitting,
shut off/volume control valve, vacuum breaker,
a 9 foot hose with a spray nozzle and a wall-
mounted hose retainer.
USAGE: All whirlpools
-PCS Pump Cover Strainer
This stainless steel strainer
is designed for use with all
hydrotherapy whirlpools to screen out
debris and avoid clogging the pump.
It easily dismantles for cleaning.
USAGE: All whirlpools
