ELECTRIC REQUIREMENTS:
Amps: 8
Volts: 115
Hertz: 60
GFI Receptacle
15”
(380) 21”
(535) tank
floor
bottom
27”
(685)
13”
(330)
25”
(635)
1/2 hp jet pump motor
Undercarriage
Handle
Variable pressure control
Thermometer
Stainless steel tank
Turbine
raising
& lowering
device
Top view
shows
drain hose
Standard
mobile
whirlpool
E-15-M E-15-M-SDP
Mobile whirlpool with
separate drain pump
E-15-MU
Mobile whirlpool
with undercarriage
E-15-MH
Mobile whirlpool
with handle
Mobile whirlpool
with sump
E-15-M-DS
Auxiliary drain valve
Sump
m -ALC Adjustable Low Chair
m -ALS Adjustable Low Stool
m -ARS Arm Rest Support
m -EG Enviro Glaze Color Powder Coating -
Specify Color:________________________
(Special Finish Consult Factory)
m -GFI Ground Fault Interrupter
m -PCS Pump Cover Strainer
Turbine Assembly
Electrical on standard turbine supplied is 115 V 60 Hz
if 220 V is required please specify:
m 50 Hz m 60 Hz
m -HL Hydro Lift (See Page HL)
Available for E-15-M or E-15-MH
Whitehall Mfg. > P.O. Box 3527 > City of Industry, CA 91744 > (800) 782-7706 > (626) 968-6681 > FAX (626) 855-4862
Extremity Whirlpools
Series
m -E Extremity Series
Capacity
m -15 Gallons
Type
m -M Mobile Whirlpool
m -M-DS Mobile Whirlpool with Sump
m -M-MH Mobile Whirlpool with Handle
m -M-MU Mobile Whirlpool with Undercarriage
m -M-SDP Mobile Whirlpool with Seperate Drain Pump
Suffix Options (See Whirlpool Option Section for Details)
m -ADH Auxiliary Drain Hose Assembly
m -AHC1 Adjustable High Chair with Casters
m -AHC2 Adjustable High Chair with Rubber Tips
E-15-M
Last Update: 9/15/09
All dimension figures in parentheses are in millimeters.
All dimensions are nominal and
subject to manufacturer’s change
without notice. Whitehall assumes
no responsibility for use of void or
suspended data. © 2008 Whitehall
Manufacturing, A Division of Acorn
Engineering Company. Please visit
www.whitehallmfg.com for most
current specifications.
Model Number & Options_____________________________________________________________ Quantity_____________
Company___________________________________________________________________ Date_________________________
Contact_______________________________________________________ Title_______________________________________
Approval for Manufacturing/Signature_______________________________________________________________________
SELECTION SUMMARY & APPROVAL FOR MANUFACTURING
MODEL NUMBER AND OPTION SELECTIONS
