Product photo/image above may show some available options

Whitehall Mfg. > P.O. Box 3527 > City of Industry, CA 91744 > (800) 782-7706 > (626) 968-6681 > FAX (626) 855-4862

L-75-S

L Series

75 Gallon

Stationary Whirlpool

L-75-S

Lo-Boy Whirlpools

Last Update: 9/15/09

Whitehall L-75-S Stationary Whirlpool is rec-

ommended for treatment of extremities, hip and

back area. It is ideal for pediatric and geriatric

applications imparting a greater degree of patient

comfort and safety.
Tank Capacity is 75 gallons.
Whirlpool Tank is 52”L x 24”W x 18”D and

is seamless welded construction, fabricated from

heavy gauge, type 304 stainless steel, polished to a

satin finish. Tank rim is reinforced with a concealed

stainless steel rod. Tank bottom is seamless, round-

ed coved design to minimize bacteria buildup. Tank

is also provided with an extended stainless steel

skirt flush to the floor line to conceal internal drain

piping.
A 2” Combination Drain and Overflow, and a Filler

Spout are provided. (See roughing-in dimensions

on the reverse side).
Turbine Raising and Lowering Device permits

adjustment of desired height and direction of water

agitation towards the area of the body to be

treated. It is spring balanced and provided with a

locking device.
Turbine Assembly functions both as agitator and

emptying device. It is equipped with Underwriters

Laboratory listed 1/2 HP jet pump motor protected

with an ABS plastic shell, and automatic thermal

overload protector, and lifetime-sealed bearings.

All parts contacting the water are stainless steel,

chrome plated brass or bronze.
Thermometer is provided with a dual scale, adjust-

able calibration, and a stem inserts into a retainer

to prevent rattle during whirlpool agitation.
GUIDE SPECIFICATIONS
Provide Whitehall Stationary Whirlpool (specify model

number and options) with a 75-gallon capacity,

52”L x 24”W x 18”D. Whirlpool shall be fab-

ricated from heavy gauge, type 304 stainless

steel. Construction shall be seamless welded and

exposed surfaces shall be polished to satin fin-

ish. Tank shall have a reinforced rim and shall

be fitted with a stainless steel skirt flush to the

floor line. Bottom of tank shall be a seamless,

rounded coved design to minimize bacteria build

up. Provide a 2” combination drain and overflow,

and a filler spout. Provide a turbine assembly

with raising and lowering device which functions

both as agitator and emptying device, permits

adjustment of desired height, direction of water

agitation, and can be locked into place. Turbine

assembly shall be UL listed 1/2 HP jet pump motor

with automatic thermal overload protector, and

lifetime-sealed bearings. Provide a 3” dial ther-

mometer with a stem retainer to prevent rattle

when whirlpool is in operation.
