Product photo/image above may show some available options
Whitehall Mfg. > P.O. Box 3527 > City of Industry, CA 91744 > (800) 782-7706 > (626) 968-6681 > FAX (626) 855-4862
S-90-M
S Series
90 Gallon
Mobile Whirlpool
S-90-M
Sports Whirlpools
Last Update: 2/14/08
Whitehall S-90-M Mobile Whirlpool is recom-
mended for treatment and prevention of sports
injuries allowing coverage of the extremities, hips
and back area. Professional, college and high
school athletic trainers find the larger design most
suitable when treating today’s athletes.
Tank Capacity is 90 gallons.
Whirlpool Tank is 46”L x 24”W x 25”D and
is seamless welded construction, fabricated from
heavy gauge, type 304 stainless steel, polished to a
satin finish. Tank rim is reinforced with a concealed
stainless steel rod. Tank is fitted with an auxiliary
drain valve. Tank bottom is a seamless, rounded
covered design to minimize bacteria buildup.
Heavy Duty Swivel Casters support all mobile
models. Rear pair of casters are lockable for stabi-
lizing whirlpool during treatment.
Turbine Raising and Lowering Device permits
adjustment of desired height and direction of
water agitation towards the area of the body to be
treated. It is spring balanced and provided with a
locking device.
Turbine Assembly functions both as agitator and
emptying device. It is equipped with Underwriters
Laboratory listed 1/2 HP jet pump motor protected
with an ABS plastic shell, and automatic thermal
overload protector, and lifetime-sealed bearings.
All parts contacting the water are stainless steel,
chrome plated brass or bronze.
Thermometer is provided with a dual scale, adjust-
able calibration, and a stem inserts into a retainer
to prevent rattle during whirlpool agitation.
Guide Specifications
Provide Whitehall Mobile Whirlpool (specify model
number and options) with a 90-gallon capacity,
46”L x 24”W x 25”D. Whirlpool shall be fab-
ricated from heavy gauge, type 304 stainless
steel. Construction shall be seamless welded and
exposed surfaces shall be polished to satin finish.
Tank shall have a reinforced rim and shall be fitted
with an auxiliary drain valve. Bottom of tank shall
be a seamless, rounded coved design to minimize
bacteria build up. Whirlpool shall have heavy duty
swivel casters with locking device on rear pair of
casters. Provide a turbine assembly with raising
and lowering device which functions both as agi-
tator and emptying device, permits adjustment of
desired height, direction of water agitation, and
can be locked into place. Turbine assembly shall
be UL listed 1/2 HP jet pump motor with auto-
matic thermal overload protector, and lifetime-
sealed bearings. Provide a thermometer with a
stem retainer to prevent rattle when whirlpool is in
operation.
