Whitehall Manufacturing L-105-M User Manual
Lo-boy whirlpools, L series 105 gallon mobile whirlpool

Whitehall L-105-M Mobile Whirlpool is
recommended for treatment of extremities, hip
and back area and allows space for exercising.
Tank Capacity is 105 gallons.
Whirlpool Tank is 66"L x 24"W x 18"D and is
seamless welded construction, fabricated from
heavy gauge, type 304 stainless steel, polished
to a satin finish. Tank rim is reinforced with a
concealed stainless steel rod. Tank bottom is a
seamless, rounded covered design to minimize
bacteria buildup.
Heavy Duty Swivel Casters support all
mobile models. Rear pair of casters are lockable
for stabilizing whirlpool during treatment.
Turbine Raising and Lowering Device
permits adjustment of desired height and
direction of water agitation towards the area of
the body to be treated. It is spring balanced
and provided with a locking device.
Turbine Assembly functions both as agitator
and emptying device. It is equipped with
Underwriters Laboratory listed 1/2 HP jet pump
motor protected with an ABS plastic shell, and
automatic thermal overload protector, and
lifetime-sealed bearings. All parts contacting
the water are stainless steel, chrome plated
brass or bronze.
Product photo/image above may show some available options
Whitehall Mfg. > P.O. Box 3527 > City of Industry, CA 91744 > (800) 782-7706 > (626) 968-6681 > FAX (626) 855-4862
Last Update: 12/12/13
Thermometer is provided with a dual scale,
adjustable calibration, and a stem inserts into a
retainer to prevent rattle during whirlpool agita-
tion.
GUIDE SPECIFICATIONS
Provide Whitehall Mobile Whirlpool (specify
model number and options) with a 105-gallon
capacity, 66"L x 24"W x 18"D. Whirlpool shall
be fabricated from heavy gauge, type 304
stainless steel. Construction shall be seamless
welded and exposed surfaces shall be polished
to satin finish. Tank shall have a reinforced rim
and shall be fitted with an auxiliary drain valve.
Bottom of tank shall be a seamless, rounded
coved design to minimize bacteria build up.
Whirlpool shall have heavy duty swivel casters
with locking device on rear pair of casters.
Provide a turbine assembly with raising and
lowering device which functions both as agitator
and emptying device, permits adjustment of
desired height, direction of water agitation, and
can be locked into place. Turbine assembly shall
be UL listed 1/2 HP jet pump motor with auto-
matic thermal overload protector, and lifetime-
sealed bearings. Provide a thermometer with a
stem retainer to prevent rattle when whirlpool
is in operation.
L Series
105 Gallon
Mobile Whirlpool
Model L-105-M
Lo-Boy Whirlpools
Please visit www.whitehallmfg.com
for most current specifications.
