Product photo/image above may show some available options
Whitehall Mfg. > P.O. Box 3527 > City of Industry, CA 91744 > (800) 782-7706 > (626) 968-6681 > FAX (626) 855-4862
F-270-S
F Series
270 Gallon
Stationary Full
Body Immersion Tank
(Hubbard Tank)
F-270-S
Full Body Immersion Tanks
Last Update: 9/15/09
Whitehall Model F-270-S Full Body Immersion
Tank is recommended for treatment of upper and
lower extremities permitting patients full body
immersion, room for body motion and exercise.
This Hubbard style tank with figure “8” configura-
tion allows therapists easy access to assure patient
comfort.
Tank Capacity is 270 gallons.
Hubbard Tank figure “8” configuration is overall
93”L x 64”W x 22”D and is seamless welded
construction, fabricated from heavy gauge, type
304 stainless steel, polished to a satin finish. Tank
bottom is a rounded covered design to minimize
bacteria buildup. Tank has a reinforced stainless
steel base supported by adjustable stainless steel
legs. Tank fittings are two1-1/4” OD overflows, one
1-1/4” NPT filler spout, one lever operated quick
open/close drain valve and an adjustable head rest.
Turbine Raising and Lowering Device permits
adjustment of desired height and direction of
water agitation towards the area of the body to be
treated. It is spring balanced and provided with a
locking device.
Twin Turbine Assemblies are mounted
on carriages with automatic counter balance.
Assemblies may be moved along the tank length
for the most advantageous treatment position.
Each assembly is equipped with Underwriters
Laboratory listed 1/2 HP jet pump motor protected
with an ABS plastic shell, and automatic thermal
overload protector, and lifetime-sealed bearings.
All parts contacting the water are stainless steel,
chrome plated brass or bronze.
Thermometer is provided with a dual scale,
adjustable calibration, and a stem inserts into a
retainer to prevent rattle during whirlpool agita-
tion.
GUIDE SPECIFICATIONS
Provide Whitehall Stationary Full Body Immersion
Tank with figure “8” configuration (specify model
number and options) with a 270-gallon capacity,
93”L x 64”W x 22”D. Hubbard tank shall be
fabricated from heavy gauge, type 304 stain-
less steel. Construction shall be seamless weld-
ed and exposed surfaces shall be polished
to satin finish. Tank bottom shall be a seam-
less rounded coved design to minimize bac-
teria buildup and shall be reinforced with a
stainless steel base supported by stainless steel legs
which are adjustable. Provide twin turbine assem-
blies mounted on carriages with automatic counter-
balance. Each turbine assembly with raising and
lowering device shall permit adjustment of desired
height, direction of water agitation, and lock-
ing in place.Turbine assemblies shall have UL
listed 1/2 HP jet pump motor with automatic
thermal overload protector, and lifetime-sealed
bearings. Provide a thermometer with a stem retain-
er to prevent rattle when whirlpool is in operation.
An adjustable head rest assembly is also provided.
