Product photo/image above may show some available options
Whitehall Mfg. > P.O. Box 3527 > City of Industry, CA 91744 > (800) 782-7706 > (626) 968-6681 > FAX (626) 855-4862
F-425-S
F Series
425 Gallon
Stationary Full
Body Immersion Tank
(Large Hubbard Tank)
F-425-S
Full Body Immersion Tanks
Last Update: 4/2/12
Whitehall Model F-425-S Full Body Immersion
Tank is recommended for treatment of upper and
lower extremities permitting patients full body
immersion, room for body motion and exercise. This
Hubbard style tank with figure “8” configuration
allows therapists easy access to assure patient
comfort.
Tank Capacity is 425 gallons.
Hubbard Tank figure “8” configuration is
overall 106”L x 77”W x 22”D and is seamless
welded construction, fabricated from heavy gauge,
type 304 stainless steel, polished to a satin finish.
Tank bottom is a rounded coved design to minimize
bacteria buildup. Tank has a reinforced stainless
steel base supported by adjustable stainless steel
legs. Tank fittings are two 1-1/4” OD overflows,
one 1-1/4” NPT filler spout, one lever operated
quick open/close drain valve and an adjustable
head rest.
Turbine Raising and Lowering Device permits
adjustment of desired height and direction of
water agitation towards the area of the body to be
treated. It is spring balanced and provided with a
locking device.
Twin Turbine Assemblies are mounted
on carriages with automatic counter balance.
Assemblies may be moved along the tank length
for the most advantageous treatment position.
Each assembly is equipped with 1/2 HP jet pump
motor protected with an ABS plastic shell, and
automatic thermal overload protector, and lifetime-
sealed bearings. All parts contacting the water are
stainless steel, chrome plated brass or bronze.
Thermometer is provided with a dual scale,
adjustable calibration, and a stem inserts into a
retainer to prevent rattle during whirlpool agitation.
GUIDE SPECIFICATIONS
Provide Whitehall Stationary Full Body Immersion
Tank with figure “8” configuration (specify model
number and options) with a 425-gallon capacity,
106”L x 77”W x 22”D. Hubbard tank shall be
fabricated from heavy gauge, type 304 stainless
steel. Construction shall be seamless welded and
exposed surfaces shall be polished to satin finish.
Tank bottom shall be a seamless rounded coved
design to minimize bacteria buildup and shall be
reinforced with a stainless steel base supported by
stainless steel legs which are adjustable. Provide
twin turbine assemblies mounted on carriages
with automatic counter-balance. Each turbine
assembly with raising and lowering device shall
permit adjustment of desired height, direction
of water agitation, and locking in place. Turbine
assemblies shall have 1/2 HP jet pump motor with
automatic thermal overload protector, and lifetime-
sealed bearings. Provide a thermometer with a
stem retainer to prevent rattle when whirlpool is in
operation. An adjustable head rest assembly is also
provided.
