Whitehall Manufacturing 1840FA - Manual

Recessed Paper Holder is die formed from
type 304 stainless steel with exposed surfaces
polished to a satin finish. Paper Holder is
arranged to be installed on finished wall from
the front. Wide flange is turned back and
trimmed to provide a uniform flat surface,
assuring a tight fit on the wall. When Paper
Holder is mounted on the finished wall,
the recommended installation is
approximately 18" above the toilet seat and
12" off of toilet centerline. Paper Holder has 4
countersunk holes to accept tamper-resistant
mounting screws. Anchor shields by others.
MODEL NUMBER AND OPTIONS SELECTION:
BASE MODEL NUMBER
o
1840FA Recessed Paper Holder (Stainless Steel)
o 1840FA-EG10 Recessed Paper Holder (White)
Whitehall Mfg. > P.O. Box 3527 > City of Industry, CA 91744 > (800) 782-7706 > (626) 968-6681 > Fax (626) 855-4862
1840FA
Whitehall Mfg. > P.O. Box 3527 > City of Industry, CA 91744 > (800) 782-7706 > (626) 968-6681 > Fax (626) 855-4862
7" SQ.
(178)
4
3
4
"
(114)
5"
(127)
1840FA
5
1
4
"
(133)
NOTES:
1. 1/4”-20 Tamper-Resistant Screws.
2. Wall Anchors By Others.
1
2
Model Number & Options______________________________________________Quantity___________
Company_________________________________________________________Date_______________
Contact_____________________________________Title_____________________________________
Approval for Manufacturing/Signature_____________________________________________________
SELECTION SUMMARY & APPROVAL FOR MANUFACTURING
Model Number & Options______________________________________________Quantity___________
Company_________________________________________________________Date_______________
Contact_____________________________________Title_____________________________________
Approval for Manufacturing/Signature_____________________________________________________
SELECTION SUMMARY & APPROVAL FOR MANUFACTURING
1840FA
Recyclable
Product
Member of
U.S. Green
Building
Council
All dimensions are nominal and subject to
manufacturer's change without notice. Whitehall
assumes no responsibility fo use of void or
superseded data
© Whitehall Manufacturing,
Member of Morris Group International.
Please visit www.whitehallmfg.com for most
current specifications.
Best-Care
™
Healthcare and Ligature
Resistant Products
Last Update: 10/23/13
