Whitehall Manufacturing 1840 series User Manual
Best-care

Recessed Paper Holder
Paper holder is die formed from type 304 stainless
steel with exposed surfaces polished to a satin
finish. Paper Holder is arranged to be installed on
finished wall from an accessible pipe chase.
Optional Wall Sleeve is recommended for all
installations to provide required wall openings.
Models for wall thickness up to 5" thick are
furnished with a heavy gage galvanized steel bolted
back plate. Models for thicker walls are similar
except that the back plate is furnished with 1/4" full
thread studs and nuts which permanently anchor
the assembly. If Paper Holder is mounted on the
back wall of toilet, recommended installation is
approximately 18" above toilet seat, 12" off of toilet
centerline.
Whitehall Mfg. > P.O. Box 3527 > City of Industry, CA 91744 > (800) 782-7706 > (626) 968-6681 > Fax (626) 855-4862
1840
MODEL NUMBER AND OPTIONS SELECTION:
BASE MODEL NUMBER
o
1840-1IN
Recessed Paper Holder
(Stainless Steel)
o
1840-8IN
Recessed Paper Holder
(Stainless Steel)
o
1840-12IN
Recessed Paper Holder
(Stainless Steel)
o
1840-EG10-1IN
Recessed Paper Holder
(White)
o
1840-EG10-8IN
Recessed Paper Holder
(White)
o
1840-EG10-12IN
Recessed Paper Holder
(White)
WALL THICKNESS AND TYPE (Must Specify):
Thickness ______________
Type:
Concrete
Block
Steel
Product Options:
-SW
Wall Sleeve
q
q
q
q
1840
Model Number & Options______________________________________________Quantity___________
Company_________________________________________________________Date_______________
Contact_____________________________________Title_____________________________________
Approval for Manufacturing/Signature_____________________________________________________
SELECTION SUMMARY & APPROVAL FOR MANUFACTURING
Model Number & Options______________________________________________Quantity___________
Company_________________________________________________________Date_______________
Contact_____________________________________Title_____________________________________
Approval for Manufacturing/Signature_____________________________________________________
SELECTION SUMMARY & APPROVAL FOR MANUFACTURING
1840
1
7" SQ.
(178)
5"
(127)
1
3
4
"
NOTES:
1. Wall Mounting Hardware.
Recyclable
Product
Member of
U.S. Green
Building
Council
All dimensions are nominal and subject to
manufacturer's change without notice. Whitehall
assumes no responsibility fo use of void or
superseded data
© Whitehall Manufacturing,
Member of Morris Group International.
Please visit www.whitehallmfg.com for most
current specifications.
Best-Care
™
Healthcare and Ligature
Resistant Products
Last Update: 10/23/13
