4121ADA
Surgical Scrub Sinks
BASE MODEL NUMBER
q -4121ADA Compact Surgical Scrub Sink (1 Station)
MOUNTING
q -MC Mounting Carrier
Product Options
q -HTR Chronomite Instantaneous Water Heater
(Refer to Chronomite Labs at
http://chronomite.com for applications and
sales assistance, supplied by Chronomite for
field installation)
q -LFN Laminar Flow Nozzle 1.5 GPM
q -SWV Swivel Nozzle on Gooseneck
q -EYW Eyewash
Whitehall Mfg. > P.O. Box 3527 > City of Industry, CA 91744 > (800) 782-7706 > (626) 968-6681 > Fax (626) 855-4862
1. Gooseneck Spout Assembly.
NOTES:
2. Flat Strainer Drain.
MODEL# 4121ADA-MC-EYW-LFN
3. Removable Access Panel.
4. Infrared Sensor.
5. Optional -EYW Eyewash
34"
(864)
9"
(229)
7
1
4
"
(184)
4
32
1
4
"
(819)
36"
(914)
3
2
5
4"
(102)
14
5
8
"
(371)
23
3
4
"
(603)
3
7
3
4
"
(197)
36"
(914)
1
1
